2.0mm Brass Right Angle Box Header PCB Connector for LED Lighting Equipment

Name: 20mm Brass Right Angle Box Header PCB Connector for LED Lighting Equipment
Brand: XTKCONN
Price: 1 USD

Quality 2.0mm Brass Right Angle Box Header PCB Connector for LED Lighting Equipment for sale

Model Number : female header

Price : Negotiable Price

Packaging Details : Inner Package:in Reel; Outer Package: Reel In Carton

Payment Terms : L/C,T/T,Payyal

Durability : High

Certification : CE,SGS,ROHS,ISO9001

Supply Ability : 3KK Pcs

Material : Plastic

Connection Type : Snap-On

Contact Pin Material : Phosphor Bronze

Delivery Time : 5-7 Days

Package : Tape Wrapping

Brand Name : XTKCONN

Termination Style : Solder

MOQ : 1000pcs

Contact Now

2.0mm Brass Right-Angle Box Header & Ejector Header PCB Connector for LED Lighting

Highlight

✅ Rich customization portfolio: straight pin / right‑angle / SMT mounting; customizable plastic housing height for different PCB stacking & enclosure space
✅ SMT pick‑and‑place ready: optional suction cap for automated mounting equipment
✅ Tape & Reel / Tube packaging available, directly compatible with SMT assembly lines
✅ Brass contact material, stable signal transmission for LED lighting systems
✅ Polarized shroud housing, anti‑mis‑mating, prevent pin bending during assembly
✅ RoHS & UL94 V‑0 compliant, fit for indoor & outdoor LED lighting projects

Product Description

Item	Parameter Details
Electrical Performance
Pitch	2.0 mm
Rated Current	2 A per contact
Rated Voltage	250 V AC/DC
Contact Resistance	≤20 mΩ (initial)
Insulation Resistance	≥1000 MΩ
Withstanding Voltage	500 V AC, 1 minute
Mechanical Performance
Number of Positions	Dual‑row: 4P ~ 64P
Mounting Style	Straight / Right‑Angle(90°) / SMT
Mating Cycles	500 cycles minimum
Polarization	Yes, anti‑mis‑insertion
Material & Plating
Contact Material	Brass
Contact Plating	Tin over nickel; optional gold flash / selective gold plating
Insulator Housing	PBT / LCP high‑temp thermoplastic
Flammability	UL94 V‑0
Environment & Soldering Guide
Operating Temperature	-40℃ ~ +105℃
Compliance	RoHS‑2 compliant
Reflow Soldering	Peak 260℃, 5‑10 seconds (for SMT version)
Wave Soldering	230℃, 5‑10 seconds (for THT version)

Compatibility & Cross‑Reference

Note: Always verify pin‑count, mounting orientation, housing height & plating before drop‑in replacement. Our 2.0 mm Box Header & Ejector Header can serve as cost‑effective alternatives for mainstream brand series:

Compatible with TE, Molex, JAE 2.0 mm pitch shrouded ejector header series for LED & signal interconnection.
Supports custom footprint adjustment to match customer’s existing PCB for direct replacement.
Avoid long OEM lead‑time (12‑20 weeks) while maintaining mechanical & electrical compatibility.

Send us your competitor part number, we will confirm matching solution for you.

2.0mm Brass Right Angle Box Header PCB Connector for LED Lighting Equipment

Product Features

Shrouded box‑type housing protects brass pins from physical damage during production & transportation
Ejector latch design for secure ribbon cable locking, easy cable release for maintenance
Multiple mounting options (straight/right-angle / SMT) solve limited cabinet / PCB layout space
Customizable plastic height to fit different enclosure gap requirements
Optional suction cap for SMT variant, supports high‑speed automatic pick‑and‑place
Polarization key prevents reverse mating, reducing on‑site assembly failure rate
Strict dimension control for consistent mating with standard 2.0 mm IDC flat ribbon cables
